“Hi” series of products:compared with the same cooling rate requirements, the machine efficiency can increase by more than 30%.
Adopt 262K color high performance touch screen.
Adopt 128G data memory, can save real-time test data for a long time.
This series features world-class high-efficiency refrigeration technology. Compared with the same cooling rate requirement, the efficiency of the chiller can be increased by more than 30%. At the same time, it adopts a brand-new appearance style and a new generation of operating system, providing you with a new generation of climatic environment reliability test equipment that is easy to use, efficient, safe, capable of long-term data retention, and convenient for accessing test data as needed.
Prooduct Name |
High-Low Temperature Test Chamber |
Prooduct Model |
HT3-650/2F |
HT4-330/3F |
HT4-1000/3 |
HT7-330/2F |
HT7-1000/6 |
HT7-2000/10 |
Working chamber volume |
646L |
326L |
1127L |
326L |
1045L |
2025L |
Working chamber dimensions
(mm) |
W |
850 |
580 |
1100 |
580 |
1100 |
1500 |
H |
950 |
750 |
1000 |
750 |
1000 |
1200 |
D |
800 |
750 |
1025 |
750 |
950 |
1125 |
External dimensions
(mm) |
W |
1050 |
780 |
1300 |
780 |
1300 |
1700 |
H |
2030 |
1830 |
2080 |
1830 |
2080 |
2280 |
D |
1840 |
1790 |
2065 |
1790 |
2065 |
2365 |
Heating/Cooling Rate |
2.1℃/min |
2.2℃/min |
2.5℃/min |
2.2℃/min |
6.4℃/min |
9.8℃/min |
Temperature range |
-30~+180℃ |
-40~+180℃ |
-70~+180℃ |
Temperature fluctuation |
±0.1~±0.5℃ |
Temperature uniformity |
1~2℃ |
Temperature deviation |
±0.5~±2℃ |
