“S” series of products:compared with the same cooling rate requirements, the machine efficiency can increase by more than 30%.
Adopt 262K color high performance touch screen.
Adopt 128G data memory, can save real-time test data for a long time.
This series features world-class high-efficiency refrigeration technology. Compared with the same cooling rate requirement, the efficiency of the chiller can be increased by more than 30%. At the same time, it adopts a brand-new appearance style and a new generation of operating system, providing you with a new generation of climatic environment reliability test equipment that is easy to use, efficient, safe, capable of long-term data retention, and convenient for accessing test data as needed.
Prooduct Name |
High-Low Temperature Test Chamber |
Prooduct Model |
ST3-1000/2F |
ST4-650/3F |
ST4-1900/2 |
ST7-550/14 |
ST7-1500/2FPro |
ST7-2000/25 |
Working chamber volume |
1127L |
646L |
1880L |
565L |
1595L |
2025L |
Working chamber dimensions
(mm) |
W |
1100 |
850 |
2000 |
850 |
1100 |
1500 |
H |
1000 |
950 |
1000 |
950 |
1000 |
1200 |
D |
1025 |
800 |
940 |
700 |
1450 |
1125 |
External dimensions
(mm) |
W |
1300 |
1050 |
2200 |
1050 |
1300 |
1700 |
H |
2080 |
2030 |
2080 |
2030 |
2080 |
2280 |
D |
2065 |
1840 |
1930 |
1940 |
2490 |
2965 |
Heating/Cooling Rate |
1.8℃/min |
2.7℃/min |
2.2℃/min |
13.8℃/min |
2.3℃/min |
25℃/min |
Temperature range |
-30~+180℃ |
-40~+180℃ |
-70~+180℃ |
Temperature fluctuation |
±0.1~±0.5℃ |
Temperature uniformity |
1~2℃ |
Temperature deviation |
±0.5~±2℃ |
